FLYBOX
All our environmental monitoring platforms are integrated with the Flybox data logger. Its hardware is designed for robustness and versatility, featuring multiple protection circuits and numerous I/O ports out of the box.
With an integrated LTE modem and a standard Ethernet port, Flybox can work autonomously or use an existing solution for internet connectivity. It can even function as a gateway for other devices.
SMART DATA-LOGGER
The web-based control panel allows seamless management of a Flybox-controlled system. Measurement intervals and other settings, such as upload credentials can be updated. The winch on profiling systems can be manually controlled in real time. The software can be adapted to new requirements on the field with remote firmware update
TWO-WAY COMMUNICATION
ALERTS
The built-in alerting system notifies users of changes in GPS position, critical battery levels or sensor malfunctions. Alerts can be delivered by email, Slack or other instant messaging app.
System health can be monitored through a web-browser-based user interface, ensuring optimal performance.
ROBUST SOFTWARE
Based on an up-to-date Linux kernel, the software has a rock-solid foundation. Every component is optimized for stable and secure operation, with the understanding that the device has to work unsupervised for extended periods in remote locations.
The software platform is designed to accommodate any custom requirements a deployment may have enabling communications with virtually any physically compatible sensor, integration with existing IT backends and control of complex systems consisting of multiple valves, pumps and sensors.
Power supply
Input Range 9 to 30VDC
DC Power Jack 2.1 / 5.5
Average Power 0.6W @ 12VDC
External interfaces
10 / 100 Mbps Ethernet RJ45 connector
Micro-SD card slot
USB 2.0 port
Nano SIM
5 relay control outputs
4xRS232 ports
2xRS485 ports
TTL port (for external solar charger diagnostics)
CAN port (for motor)
LED light power port
5 Digital I/Os
Software Platform
Flydog provides powerful software applications and web-based cloud services. Developed in-house using the latest computing and web technologies, it is designed for comprehensive data management and infrastructure monitoring/control. The platform features a user-friendly interface, accessible via web or software application, designed to simplify interaction for end-users.
